  • ITW Formex GK 17 Polypropylene Insulation Paper for Transformers Application

    Short Description:

    1.0.017in thickness, with jumbo roll size 610mmx 305meter
    2.2. UL 94V-O fire certificated polypropylene (PP) and FORMEX patented formula extruded sheet material;
    3. Superior electric surge shielding in industrial and consumer electronic equipment
    4. Chemical Resistance ;
    5. Very low water absorption for nearly 0.06%;
    6. Capable of working for a long time in the high temperature of 115 ℃;
    7. High dielectric breakdown voltage, FORMEX GK-17 can reach 20,292V
    8. Suitable for die cutting and easy maintenance with flexible characteristics;
    9. High adhesive performance characteristics for graphic printed stablly ;
    10. Easy for die cutting or laser cutting to achieve a finished part design
    11. Cost-effective when compared with similar productsMulti-Sized Value Bundle 1/8’’, 1/4’’, 1/2’’, 1’’ with Silicone Adhesive for Masking, Soldering.


    Product Detail

    Product Tags

    Application:

    Power supplies, transformers, and inverters
    Electric vehicle battery packs and charging equipment
    Servers and data storage system
    Telecommunications equipment
    LED Lighting
    UPS and surge protectors
    Medical Devices
    HVAC Equipment and Appliances
    EMI Shielding Laminates
    Battery Insulation Gasket
